A150 Laboratory Conductivity/TDS/Salinity/Conductivity Ash Meter

High-precision salinity meter contains 5 measurement modes for measuring conductivity, TDS, salinity, resistivity and conductivity ash, accuracy: 1% F.S.

Features:
• 1 to 3 points calibration with automatic recognition for conductivity standards.
• Selectable conductivity ash, cell constant (K=0.1/1/10), reference temperature (20/25°C), TDS
conversion factor, linear/non-linear/pure water compensations, percentage/seawater/practical
salinity measurement modes.
• Automatic temperature compensation corrects measurements to the reference temperature.
• Auto-read function senses and locks the measurement endpoint.

Laboratory Salinity Meter

• Timed interval readings send the measurement data to a PC or printer.
• Limit Alarm automatically alerts when reading exceeds the specified range.
• Calibration due alarm reminds the user to calibrate the meter regularly.
• Calibration log shows the date, time, calibration point and factor.
• Password protection prevents the unauthorized calibration and settings.
• Expanded memory stores or recalls up to 1000 data sets.
• Reset function automatically resumes all settings back to the factory defaults.

Specifications Ordering Info Optional Accessories Packaging

Model		A150
Conductivity
Range		0 to 20.00, 200.0, 2000 µS/cm, 20.00, 200.0 mS/cm
Resolution		0.001, 0.01, 0.1, 1, automatic
Accuracy		±0.5% F.S.
Calibration		1 to 3 points
Calibration Solutions		10 µS / 84 µS / 1413 µS / 12.88 mS / 111.8 mS
TDS
Range		0 to 10.00, 100.0, 1000 mg/L, 10.00, 200.0 g/L
Resolution		0.01, 0.1, 1, automatic
Accuracy		±1% F.S.
TDS Conversion Factor		0.1 to 1.0 (default 0.5)
Salinity
Range		0.00 to 80.00 ppt / 0.00 to 42.00 psu / 0.00 to 8.00%
Resolution		0.01
Accuracy		±1% F.S.
Resistivity
Range		0.00 to 30.00 MΩ
Resolution		0.01, 0.1, 1, automatic
Accuracy		±1% F.S.
Conductivity Ash
Range		0.00 to 100%
Resolution		0.01, 0.1, 1, automatic
Accuracy		±1% F.S.
Measurement Modes		ICUMSA GS1 / GS2
Temperature
Range		0 to 105°C / 32 to 221°F
Resolution		0.1°C/°F
Accuracy		±0.5°C / ±0.9°F
Calibration		1 point
Calibration Range		Reading ±10°C/°F
Other Specifications
Temperature Compensation		0 to 100°C / 32 to 212°F, manual or automatic
Temperature Coefficient		Linear (0.0 to 10.0%/°C) / Non-linear / Pure water
Reference Temperature		20 / 25°C
Cell Constant		2-pole electrodes (K=0.1 / 1 / 10) or 4-pole electrode
Stability Criteria		Standard / High-accuracy
Measurement Modes		Continuous / Auto-read measurement endpoint
Timed Interval Readings		10 / 30 / 60 seconds, 10 / 30 minutes or off
Calibration Due Alarm		1 to 31 days or off
High/Low Limit Alarm		Selectable
Password Protection		4 digits
Memory		Stores up to 1000 data sets
Output		USB communication interface
Connector		6-pin mini-DIN, 3.5 mm jack socket
Display		7 inch TFT LCD
Power Supply		12V DC power adapter
Environmental Conditions		0 to 50°C / 32 to 122°F, relative humidity < 80%
Dimensions		240 × 220 × 80 mm
Weight		1.7 kg

Ordering Code	Meter Includes
A150-S	CON-1 conductivity electrode
	TP-10K temperature probe
	Conductivity standard solutions 84 µS/cm, 1413 µS/cm, 12.88 mS/cm
	12V DC power adapter
A150-DL	CON-0.1 conductivity electrode
	CON-1 conductivity electrode
	TP-10K temperature probe
	Conductivity standard solutions 84 µS/cm, 1413 µS/cm, 12.88 mS/cm
	12V DC power adapter
A150-DH	CON-1 conductivity electrode
	CON-10 conductivity electrode
	TP-10K temperature probe
	Conductivity standard solutions 1413 µS/cm, 12.88 mS/cm, 111.8 mS/cm
	12V DC power adapter

Items	Description
CON-0.1 Conductivity Electrode	For measuring the pure water
CON-1 Conductivity Electrode	For measuring the general water samples
CON-10 Conductivity Electrode	For measuring the high conductivity samples
TP-10K Temperature Probe	For temperature compensation and measurement
Conductivity Standard Solutions	For conductivity calibration
USB Cable	For transferring data or connecting power adapter
Thermal Printer	For printing the measurement data
