New Products

A130 pH/Ion Meter

High performance pH/Ion meter, selectable four ion measurement methods, stores up to 1000 data.

pH Mode:
• Professional benchtop pH/ion meter is equipped with a 7 inch TFT display.
• Selectable pH buffer group (USA/NIST/DIN) or using the custom calibration solutions.
• Automatic electrode diagnosis with pH slope and offset display.
• Automatic Temperature Compensation provides accurate reading over the entire range.
• Solution temperature coefficient compensates for the pure water samples and references
  the pH to 25°C.
• Limit alarm alerts when reading exceeds range.

pH Ion Meter

ORP Mode:
• 1 point offset calibration allows adjusting the displayed value to a known standard.
• Relative and absolute millivolt modes provide the reliable ORP measurements.

Ion Mode:
• Selectable ion measurement methods, including the direct reading, known addition, known
  subtraction, sample addition and sample subtraction.
• Selectable concentration units, including the ppm, mg/L, mol/L and mmol/L.
• 2 to 5 points calibration, containing the 8 concentration points can be selected.
• Automatically recognizes the ion selective electrodes, does not need to specify type of ion.
• Electrode management is capable of storing the 3 slopes and recalling the calibration data
  of each electrode.
• Calibration report provides the details of the calibration standards and electrode slopes.

pH Ion Meter

Water Hardness Mode:
• 2 to 5 points calibration from low to high concentrations.
• Selectable measurement units (German degree, English degree, French degree, mmol/L
  and mg/L) are used for professional water hardness measurements.

Other Features:
• Calibration Due Reminder prompts user to calibrate the meter regularly.
• Stability indicator shows when a measurement is recognized as stable.
• Auto-Read feature senses and locks the measurement endpoint.
• Interval Readings automatically send the measured data to the computer or printer.
• Password protection prevents the unauthorized calibration and settings.
• Expanded memory stores and recalls up to 1000 data sets.
• Stored readings can be transferred into the computer by USB communication interface.
• Reset feature automatically resumes all settings back to factory default options.

   Model


A130

   pH



   Range


-2.000~20.000pH

   Accuracy


±0.002pH

   Resolution


0.01, 0.001pH, Selectable

   Calibration Points


1 to 5 points

   Calibration Solutions


USA, NIST, DIN, Custom

   mV



   Range


-2000.0~2000.0mV

   Accuracy


±0.2mV

   Resolution


0.1mV

   Calibration Points


1 point (Only for Relative mV mode)

   Measurement Modes


Relative and Absolute mV

   Ion



   Range


0~30000ppm, mg/L, mol/L (Refer to the range of ISE)

   Accuracy


±0.5% F.S (Monovalent), ±1% F.S (Divalent)

   Resolution


0.001, 0.01, 0.1, 1

   Calibration Points


2 to 5 points

   Calibration Solutions


0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000ppm, mg/L, mol/L

   Measurement Methods


Direct reading, Known addition, Known subtraction,



Sample addition, Sample subtraction

   Water Hardness



   Range


0.05~200mmol/L, 0~1120°dH, 0~1404°e, 0~2000°fH



0~8000mg/L (Ca2+), 0~19999mg/L (CaCO3)

   Accuracy


±1% F.S

   Resolution


0.001, 0.01, 0.1, 1

   Calibration Points


2 to 5 points

   Calibration Solutions


0.01, 0.1, 1, 10, 100mmol/L

   Measurement Units


°dH, °e, °fH, mg/L, mmol/L

   Temperature



   Range


0~105°C, 32~221°F

   Accuracy


±0.5°C

   Resolution


0.1°C

   Calibration Points


1 point

   Temperature Units


°C or °F, Selectable

   Others



   Temperature Compensation


0~100°C, 32~212°F, Manual or Automatic

   Stability Criteria


Standard or High-accuracy

   Calibration Due


1 to 31 days

   Interval Readings


10/30/60 seconds, 10/30 minutes or Off

   Reset Function


Yes

   Memory


Stores up to 1000 data sets

   Output


USB communication interface

   Connector


BNC

   Display


7 inch TFT LCD

   Power Requirements


DC12V, using AC adapter, 220VAC/50Hz

   Dimensions


240(L)×220(W)×80(H)mm

   Weight


1.7kg

   Order Code

Accessories

   A130-CN

E201-BNC pH Electrode

TP-10K Temperature Probe

pH Buffer Pouches (pH4.01/7.00/10.01)

DC12V Power Adapter

   A130-UK


P11 Glass pH Electrode (Made in UK)

TP-10K Temperature Probe

pH Buffer Pouches (pH4.01/7.00/10.01)

DC12V Power Adapter

Items Description
P11 pH Electrode Suitable for the non-high temperature liquids
P11-LiCl pH Electrode Suitable for the non-aqueous samples
P11-HA pH Electrode Suitable for the high alkalines samples
P11-NA pH Electrode Suitable for the biofuels
P12 pH Electrode Suitable for the sample in the test tube
P13 pH Electrode Suitable for the micro-volume samples
P15 pH Electrode Suitable for the low conductivity liquids
P16 pH Electrode Suitable for the Tris buffers
P18 pH Electrode Suitable for the slurries and soils
P19 pH Electrode Suitable for the semisolids
P21 pH Electrode Suitable for the colloids
P22 pH Electrode Suitable for high temperature measurements
501 ORP Electrode Suitable for the sample with strong redox potential
502 ORP Electrode Suitable for the sample with weak redox potential
Na-US Sodium Electrode Range: 0.1~23000ppm
CL-US Chloride Electrode Range: 1.8~35500ppm
F-US Fluoride Electrode Range: 0.02ppm~Saturation
Ca-US Calcium Electrode Range: 0.02~4000ppm
NO3-US Nitrate Electrode Range: 0.4~62000ppm
Br-US Bromide Electrode Range: 0.4~79900ppm
NH4-US Ammonium Electrode Range: 0.1~18000ppm
Cn-US Cyanide Electrode Range: 0.2~260ppm
Cd-US Cadmium Electrode Range: 0.01~11200ppm
Cu-US Copper Electrode Range: 0.006~6400ppm
I-US Iodide Electrode Range: 0.06~127000ppm
Pb-US Lead Electrode Range: 0.2~20700ppm
Ag-US Silver Electrode Range: 0.01~107900ppm
K-US Potassium Electrode Range: 0.04~39000ppm
S-US Sulphide Electrode Range: 0.003~32100ppm
NH3-US Ammonia Electrode Range: 0.02~17000ppm
WH-UK Water Hardness Electrode Range: 0.05~200mmol/L
Ion Standard Solutions 480mL/Bottle
Ionic Strength Adjuster 480mL/Bottle
pH Buffer Pouches (USA) pH4.01/7.00/10.01
pH Buffer Pouches (NIST) pH4.01/6.86/9.18
TP-10K Temperature Probe Special-purpose sensor

   Order Code

Dimensions

Weight

   A130-CN

300(L)×240(W)×170(H)mm

2kg

   A130-UK

300(L)×240(W)×170(H)mm

2kg
